Minelab Vanquish 540
An intelligent all-terrain metal detector powered by Multi-IQ technology, featuring 5 search modes, adjustable Iron Bias, 25 discrimination segments, Bluetooth wireless audio, and a waterproof V12 search coil.
Overview
Minelab Vanquish 540 is the flagship model in the Vanquish series, built for detectorists who want serious performance in an easy-to-use machine. Multi-IQ technology gives it the strength of several simultaneous frequencies, so it can identify coins, jewelry, and relics confidently across varied ground without manually switching frequency.
Rather than forcing you to swap frequencies or navigate complex settings, the Vanquish 540 stays simple and effective while adding professional touches: Iron Bias control, target pinpointing, 10 sensitivity levels, and 25 discrimination segments that give you full command over ignoring trash and focusing on worthwhile targets.
Its waterproof 12x9-inch V12 coil helps you cover more ground quickly, while the red LED backlight and Bluetooth wireless audio support keep detecting comfortable as conditions change. The Vanquish 540 combines speed, depth, and smart target handling in one practical machine, suited to serious treasure hunters.
Key features
Multi-IQ Technology
Synchronized multi-frequency detection that helps you find more targets in more places without switching machines.
Iron Bias Control
Switchable high/low iron bias for handling trash and difficult ground.
5 Search Modes
Coins, Relics, Jewelry, Custom, and All Metal, ready at the touch of a button.
True Tones
5 target tones and 10 volume levels for more confident target identification by ear.
10 Sensitivity Levels
Increase depth on weak signals or reduce noise in difficult conditions.
25 Discrimination Segments
High precision in selecting desired metals and silencing trash.
Bluetooth Audio
Wireless support with low-latency aptX for a more responsive detecting experience.
Technical specifications
| Depth | 3 feet |
|---|---|
| Made In | Australia |
| Warranty | 3 Years |
| Search Modes | Coins, Relics, Jewelry, Custom, All Metal |
| Custom Search Coil | Yes |
| Target Pinpointing | Yes |
| Operating Frequency | Multi-IQ |
| Sensitivity | 10 levels |
| Noise Cancel | Automatic |
| Wireless Audio | Bluetooth aptX low latency |
| Volume | 10 levels |
| Target Tones | 5 tones |
| Included Headphones | Wired headphones |
| Discrimination Segments | 25 segments |
| Target ID | Ferrous: -19 to 0, Non-ferrous: 1 to 40 |
| Depth Indicator | 5 levels |
| Iron Bias | High / Low |
| Water Resistance | Coil waterproof up to 1 meter |
| Display | Black-and-white LCD with red backlight |
| Search Coil | V12 DD elliptical coil, 12x9 inch |
| Batteries | 4 rechargeable NiMH AA batteries |
What’s in the box
- Vanquish 540 control unit
- V12 DD elliptical coil, 12x9 inch
- 4 rechargeable NiMH AA batteries
- Quad USB battery charger
- Wired headphones
- Control unit protective cover
- User manual
Ideal for
Coin hunting
A strong fit for coin hunting with the Minelab Vanquish 540.
Jewelry recovery
A strong fit for jewelry recovery with the Minelab Vanquish 540.
Relic hunting
A strong fit for relic hunting with the Minelab Vanquish 540.
Beach detecting
A strong fit for beach detecting with the Minelab Vanquish 540.
