Minelab Vanquish 540 Pro Pack
The flagship Vanquish 540 Pro Pack pairs Minelab's simultaneous multi-frequency Multi-IQ technology with two waterproof coils, wireless ML80 headphones, and adjustable iron bias — a complete, ready-to-search bundle for serious coin, relic, and jewelry hunters.
Overview
The Minelab Vanquish 540 Pro Pack is the top model in the Vanquish range, built for the serious detectorist who wants full control over their search from the very first outing. It runs on Minelab's Multi-IQ technology, which processes multiple frequencies simultaneously, combining the strength of several detectors in one machine that adjusts automatically without manual frequency selection.
The professional pack includes two waterproof coils: the 12×9-inch V12 for maximum depth and wide coverage, and the compact 8×5-inch V8 for precision in tight spaces and trash-heavy sites. It also includes wireless ML80 Bluetooth headphones for a cable-free, distraction-free search.
With adjustable iron bias, 25 discrimination segments, 5 distinct target tones, and a red LED backlight, the Vanquish 540 Pro Pack gives you the confidence to search any terrain in any lighting.
Key features
Multi-IQ technology
simultaneous multi-frequency operation that runs automatically for strong performance across all soil types.
Two coils included
the V12 for depth and coverage, and the V8 for precision in tight spaces.
Wireless Bluetooth headphones
clear audio without cables getting in the way.
Adjustable iron bias
switch between high and low settings depending on ground conditions.
25 discrimination segments and 5 tones
precise target sorting before you dig.
Automatic noise cancelling
scans 19 channels on startup to reduce electromagnetic interference.
Red backlight
clear screen visibility in low light.
Rechargeable batteries
4x AA NiMH included with charger.
Lightweight build
just 1.3 kg, with a quick-fold, quick-lock design.
3-year warranty
trusted Australian engineering from Minelab.
Technical specifications
| Depth | 3 feet |
|---|---|
| Made In | Australia |
| Warranty | 3 Years |
| Technology | Multi-IQ simultaneous multi-frequency |
| Search Modes | Coin, Relic, Jewellery, All Metal, Custom |
| Interference Cancellation | Automatic (scans 19 channels) |
| Wireless Audio | Bluetooth (ML80 headphones included) |
| Iron Bias | High (default) / Low |
| Sensitivity | 10 levels |
| Volume | 10 levels |
| Target Tones | 5 distinct tones |
| Discrimination Segments | 25 segments |
| Target ID | -9 to 40 |
| Depth Indicator | 5 levels |
| Length | Extended: 145 cm (57 in) / Folded: 76 cm (30 in) |
| Weight | 1.3 kg (2.9 lb) including batteries |
| Search Coils | V12 (12×9 in) and V8 (8×5 in) Double-D, waterproof |
| Display | Monochrome LCD with red backlight |
| Battery | 4x rechargeable AA batteries (included) |
| Water Resistance | Coil waterproof up to 1 m |
What’s in the box
- Main control unit (control box)
- V12 (12×9 in) Double-D waterproof search coil
- V8 (8×5 in) Double-D waterproof search coil
- ML80 wireless Bluetooth headphones
- 4x rechargeable AA batteries
- Battery charger
- Rain cover
- User manual
- Warranty certificate
Ideal for
Coin hunting in parks and public spaces
A strong fit for coin hunting in parks and public spaces with the Minelab Vanquish 540 Pro Pack.
Relic hunting in old fields and historical sites
A strong fit for relic hunting in old fields and historical sites with the Minelab Vanquish 540 Pro Pack.
Jewelry hunting on land and in wet sand
A strong fit for jewelry hunting on land and in wet sand with the Minelab Vanquish 540 Pro Pack.
Detecting on beaches and in shallow water
A strong fit for detecting on beaches and in shallow water with the Minelab Vanquish 540 Pro Pack.
